Specification: Customized Ag/AgCl aqueous Reference Electrode The AgCl/Ag reference electrode reaching the working electrode as close as 2 mm. the reference electrode also designed such a way that it supports inert atmosphere electrochemistry.
Specification: A well-polished stainless steel structure supporting two electrode leak-free system with a provision of air inlet and outlet along with pressure gauge to measure accurately the pressure of the air inside the cell. A corrosion-proof PTFE guide and O ring for sealing of the Electrolyte is integrated within. it offers complete a compact design fits into any bench top glove boxes.
Specification: A high quality Stainless steel 316 Swagelok type two ways tube fitting. Female Tube: inner diameter: 10 mm, Outer diameter: 11 mm with male stainless rod of 10 mm. The cell could tighten with a Spring and Teflon gasket.
Specification: A high quality Teflon lined autoclave is suitable to carry out the hydrothermal reaction at high temperature and High pressure. This reactor is mainly consist of two parts,
outer high quality stainless steel jacket (SS316) and inner Teflon Chamber where actual reaction is taking place. The maximum temperature to carry out any reaction is about 240oC while Safe operating temperature is 200oC.
Specification : A Teflon made 3 electrodes holder for the electrode outer diameter 0f 6.4 mm. The Teflon electrode holder is attached with Stainless steel stand with a Teflon base of 150 * 100 mm dimension.
Specification : A Teflon made well polished glassy carbon rod electrode along with O ring can be worked as working electrode and adaptable to Teflon holder.
Specification : A light weight photo electrochemical UV-cuvette cell with a Teflon electrochemical holder with reference and counter electode integrated in it.
Reference electrode : Standard AgCl/Ag
Counter electrode : Pt-Ir mesh with spot welded liner, diameter of the wire: 0.25 mm, Length = 40 mm with border wire, width: 6 mm
Electrochemical cell with variable volume and entry
Specification : Electrochemical Glass Cell with variable standard joints (as per as the requirement) provision of introducing electrodes in parallel to each other (for instance working and counter electrode) and reference electrode as close as 2 mm to working electrode. The cell is adaptable to inert atmosphere.
The electrochemical cell can be varied from 25 to 250 ml.
Electrochemical glass cell at constant temperature
Electrochemical glass cell at constant temperature
ET/ECELL1
Price Rs. 11200.00 (*excluding GST)
Specification : Electrochemical Glass Cell with variable standard joints (as per as the requirements) provision of introducing electrodes in parallel to each other (for instance working and counter electrode) and reference electrode as close as 2 mm to working electrode. The cell is adaptable to inert atmosphere as well as controlled temperarure. The electrochemical cell can be varied from 25 to 250ml.
